ASRock H81M-VG4 R4.0 4th Gen Micro ATX Motherboard

8,000.00৳

  • Model: H81M-VG4 R4.0
  • Supports 4th Generation Intel Core Processors (Socket 1150)
  • Supports Dual Channel DDR3 1600
  • 1 PCIe 2.0 x16, 1 PCIe 2.0 x1
  • Graphic Output: D-Sub

Hotline: 01977055921 (10:00AM TO 8:00PM)

ASRock H81M-VG4 R4.0 4th Gen Micro ATX Motherboard

Supported CPU Supports New 4th and 4th Generation Intel Core i7/i5/i3/Xeon/Pentium/Celeron Processors (Socket 1150)
Supports Intel Turbo Boost 2.0 Technology
Chipset Intel H81
BIOS 32Mb AMI UEFI Legal BIOS with multilingual GUI support
ACPI 1.1 Compliant wake up events
SMBIOS 2.3.1 support
CPU, DRAM Voltage multi-adjustment
Form Factor Micro ATX Form Factor: 7.5-in x 6.7-in, 19.1 cm x 17.0 cm
Solid Capacitor design
Audio 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec)
Supports Surge Protection
PCI 1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)
1 x PCI Express 2.0 x1 Slot
Memory Type Dual Channel DDR3/DDR3L Memory Technology
Slots 2 x DDR3/DDR3L DIMM Slots
Supported Memory Supports DDR3/DDR3L 1600 / 1333/1066 non-ECC, un-buffered memory
Maximum Memory 16GB
Graphics Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600
Pixel Shader 5.0, DirectX 11.1
Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz
D-Sub (s) 1 x D-Sub Port
LAN Port (s) PCIE x1 Gigabit LAN 10/100/1000 Mb/s
Realtek RTL8111H
Supports Wake-On-LAN
Supports Lightning/ESD Protection
Supports Energy Efficient Ethernet 802.3az
Supports PXE
USB (s) 2 x USB 2.0 Ports (Supports ESD Protection)
2 x USB 3.2 Gen1 Ports (Supports ESD Protection)
Supported Storage 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
Internal I/O Ports 1 x Chassis Intrusion and Speaker Header
1 x CPU Fan Connector (4-pin)
1 x Chassis Fan Connector (4-pin)
1 x 24 pin ATX Power Connector
1 x 4 pin 12V Power Connector
1 x Front Panel Audio Connector
TPM (Trusted Platform Module ) 1 x TPM Header
1 x SPI TPM Header
Manufacturing Warranty 3 years warranty

What is the ASRock H81M-VG4 R4.0 4th Gen Micro ATX Motherboard Price in Bangladesh ?

The ASRock H81M-VG4 R4.0 4th Gen Micro ATX Motherboard Price in BD is 8,000 in Today’s 29th November 2023 Market. Paragon Computer BD Offers you with special price Which is also In Stock Now at our Showroom. Follow us on Facebook For Regular updates & offers. Subscribe to Our YouTube Channel for product reviews.

ASRock H81M-VG4 R4.0 4th Gen Micro ATX Motherboard Review in BD

Product Price

8,000

Stock Status In Stock
Specification Model: ASRock H81M-VG4 R4.0 4th Gen Micro ATX Motherboard

Supported CPU: S4th and 4th Generation Intel Core i7/i5/i3.

Supported Memory: 2x DIMM, Max. 16GB, DDR3

Graphics support: Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz
